| Manufacturer | LIEBHERR |
| Model | RL54 Litronic Sideboom Pipelayer |
| Year of manufacture | 2016 |
| Recorded hours | 4.000 hours |
| Operating weight | 45.900 kgs |
| Lift capacity | 70.000 kgs |
| Certification | CE |
| Engine make & model | LIEBHERR D936L A6 |
| Engine output | 210 kW |
| Emission standards | EU Stage IIIA & USA EPA Tier3 |
| Fuel tank capacity | 535 liters |
| |
| Configuration | ROPS cab with heating |
| Air conditioning |
| Boom 8.500 mm with protection strips |
| Track pads 914 mm |
| Centre track guide |
| Acoustic back-up alarm |
| Four (04) removable counterweights |
| Hydraulic driven winch |
| Arctic kit (-40 degrees) |
| Free fall control |
| Load monitoring system |
| Hydraulic PTO to drive a mandrel or a pipefacing machine |
| Transport dimensions (LxWxH) | Base machine: 5.500 mm x 3.800 mm x 3.650 mm |
| Weight base machine: 33.660 kgs |
| Boom: 8.850 mm x 1.450 mm x 750 mm |
| Weight boom: 2.500 kgs |
| a) Counterweight - 2 units: 1.400 mm x 1.050 mm x 550 mm |
| Weight each: 990 kgs |
| b) Counterweight - 7 units: 1.200 mm x 800 mm x 550 mm |
| Weight each: 1.880 kgs |
| Remarks | Availability subject to prior rental or sale |
| Machine is located in our yard in GOOR - The Netherlands |
| Machine is available for rental as well: contact us for our rental rates |
| Product brochure | Specifications Liebherr RL54 Litronic |
| Price | Contact us for a detailed quotation including pictures and price |
| Contact Roderik van der Velde for more details:velde@maats.com | +31 (0)6 86 89 80 55 |
